• Country
• France

• Manufacturer / Brand
• Pygmy, Ciate-Pygmy (SCIP, CIATE); Paris, La Plaine St. Denis, La Courneuve

• Year
• 1933/1934

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 136513

• Number of Tubes
• 4

• Valves / Tubes
• 78 77 43 25Z5

• Main principle
• TRF without regeneration

• Tuned circuits
• 2 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• AC/DC-set / 110 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 cm = 4.7 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Club 4 lampes [deuxième version] - Pygmy, Ciate-Pygmy SCIP, CIATE

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 235 x 170 x 120 mm / 9.3 x 6.7 x 4.7 inch

• Notes
• Resistive wire line cord.

• Net weight (2.2 lb = 1 kg)
• 3.7 kg / 8 lb 2.4 oz (8.15 lb)

• Mentioned in
• "PYGMY Une grande marque pour des petits postes" Page 86 Jacques & Annie Juin Edition Radiofil

• Author
• Model page created by Marc Couque. See "Data change" for further contributors.

• Other Models

• Here you find 125 models, 92 with images and 34 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
