Radiobell 6 (6A, R.6, 2033A)

Radiobell 6 ; Bell Telephone Mfg. (ID = 148317) Radio

Radiobell 6 ; Bell Telephone Mfg. (ID = 1678058) Radio

Radiobell 6 ; Bell Telephone Mfg. (ID = 1678059) Radio

Radiobell 6 ; Bell Telephone Mfg. (ID = 1678060) Radio
Radiobell 6 ; Bell Telephone Mfg. (ID = 96086) Radio Radiobell 6 ; Bell Telephone Mfg. (ID = 97021) Radio
Radiobell 6 ; Bell Telephone Mfg. (ID = 111732) Radio Radiobell 6 ; Bell Telephone Mfg. (ID = 53966) Radio
Radiobell 6 ; Bell Telephone Mfg. (ID = 111722) Radio Radiobell 6 ; Bell Telephone Mfg. (ID = 111731) Radio
Radiobell 6 ; Bell Telephone Mfg. (ID = 1057810) Radio Radiobell 6 ; Bell Telephone Mfg. (ID = 1057871) Radio
Radiobell 6 ; Bell Telephone Mfg. (ID = 1057872) Radio Radiobell 6 ; Bell Telephone Mfg. (ID = 1057873) Radio
Use red slider bar for more.
Radiobell 6 ; Bell Telephone Mfg. (ID = 96086) Radio
Bell Telephone Mfg.: Radiobell 6 [Radio] ID = 96086 525x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Radiobell 6 (6A, R.6, 2033A), Bell Telephone Mfg. Co. (Radiobell); Antwerp

Country:  Belgium
Manufacturer / Brand:  Bell Telephone Mfg. Co. (Radiobell); Antwerp
Brand

Radiobell
Year: 1934/1935 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6A7 78 75 77 43 1D6
Main principle Superheterodyne (common); ZF/IF 145 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage 120; 135; 150; 225; 250 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 29 cm = 11.4 inch
Power out 2.2 W (unknown quality)
from Radiomuseum.org Model: Radiobell 6 - Bell Telephone Mfg. Co.
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 440 x 545 x 250 mm / 17.3 x 21.5 x 9.8 inch
Notes Codex J.V. AS 5724
Vademecum Staleman: 250 Hfl.
Net weight (2.2 lb = 1 kg) 13.3 kg / 29 lb 4.7 oz (29.295 lb)
Price in first year of sale 2'650.00 BFR
External source of data Roger Roth
Source of data -- Original prospect or advert
Mentioned in -- Schematic
Literature/Schematics (1) Technisch- Commercieel - Radio Vademecum Staleman
Literature/Schematics (2) Manuel de la Radio 1940, van Cortenberghe
Literature/Schematics (3) Brans, P.H. Radio Schema's, Antwerpen (1943 deel II)

Model page created by Roger Roth. See "Data change" for further contributors.



All listed radios etc. from Bell Telephone Mfg. Co. (Radiobell); Antwerp
Here you find 274 models, 238 with images and 111 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
