• Country
• Belgium

• Manufacturer / Brand
• Bell Telephone Mfg. Co. (Radiobell); Antwerp

• Year
• 1939/1940

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 97121

• • Brand: Radiobell

• Number of Tubes
• 6

• Valves / Tubes
• ECH3 EF9 EBC3 EL3 6G5 or 6H5 EZ2

• Main principle
• Superheterodyne (common); ZF/IF 440 kHz

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 115-250 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Radiobell 136 - Bell Telephone Mfg. Co.

• Shape
• Tablemodel, low profile (big size).

• Notes
• Vademecum Staleman: 136 Hfl.

• Price in first year of sale
• 2,190.00 BFR

• Source of data
• -- Original prospect or advert

• Mentioned in
• Technisch- Commercieel - Radio Vademecum Staleman

• Author
• Model page created by John Koster. See "Data change" for further contributors.
