Radiobell 5 (5U, 2302A)

Radiobell 5 ; Bell Telephone Mfg. (ID = 148360) Radio

Radiobell 5 ; Bell Telephone Mfg. (ID = 1678055) Radio

Radiobell 5 ; Bell Telephone Mfg. (ID = 1678056) Radio

Radiobell 5 ; Bell Telephone Mfg. (ID = 1678057) Radio
Radiobell 5 ; Bell Telephone Mfg. (ID = 116656) Radio Radiobell 5 ; Bell Telephone Mfg. (ID = 116657) Radio
Radiobell 5 ; Bell Telephone Mfg. (ID = 116658) Radio Radiobell 5 ; Bell Telephone Mfg. (ID = 665991) Radio
Radiobell 5 ; Bell Telephone Mfg. (ID = 1056539) Radio Radiobell 5 ; Bell Telephone Mfg. (ID = 1056805) Radio
Radiobell 5 ; Bell Telephone Mfg. (ID = 1057869) Radio
Use red slider bar for more.
Radiobell 5 ; Bell Telephone Mfg. (ID = 116656) Radio
Bell Telephone Mfg.: Radiobell 5 [Radio] ID = 116656 800x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model Radiobell 5 (5U, 2302A), Bell Telephone Mfg. Co. (Radiobell); Antwerp

Country:  Belgium
Manufacturer / Brand:  Bell Telephone Mfg. Co. (Radiobell); Antwerp
Brand

Radiobell
Year: 1934/1935 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6A7 78 75 43 25Z5
Main principle Superheterodyne (common)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage AC/DC-set / 115, 220 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Radiobell 5 - Bell Telephone Mfg. Co.
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 530 x 320 x 245 mm / 20.9 x 12.6 x 9.6 inch
Notes Codex J.V. US4724
van Dijk: 1990 Bfr.
Manuel de la Radio: 1850 Bfr.
Net weight (2.2 lb = 1 kg) 11.5 kg / 25 lb 5.3 oz (25.33 lb)
Price in first year of sale 1'900.00 BFR
Source of data -- Original prospect or advert
Mentioned in Manuel de la Radio 1940, van Cortenberghe
Literature/Schematics (1) -- Schematic

Model page created by Patrick Mergan † Dec. 21, 2009. See "Data change" for further contributors.



All listed radios etc. from Bell Telephone Mfg. Co. (Radiobell); Antwerp
Here you find 273 models, 237 with images and 111 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Bell Telephone Mfg.: Radiobell 5
Threads: 1 | Posts: 1
Hits: 2126     Replies: 0
radiobell: 2302A (2302 A); Bell
Georges Van Campenhout
17.Sep.10
  1

Good afternoon,



I think that this ID and ID 82686 cover the same set.

I found a Radiobell 2302A where the back panel states Radiobell 5 2302A.
Plse see picture.



Best regards

Attachments


Bell Telephone Mfg.: Radiobell 5
