• Year
  • 1960 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 123016
    • Brand: Radiobell

 Technical Specifications

  • Number of Tubes
  • 5
  • Number of Transistors
  • Main principle
  • Superheterodyne (common); Export model
  • Wave bands
  • Broadcast, Long Wave and FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 110-130; 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Radiobell Favori 116A - Bell Telephone Mfg. Co.
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 330 x 200 x 165 mm / 13 x 7.9 x 6.5 inch
  • Notes
  • English lettering on the dial scale (Off, P.U., M, L, FM). Oval speaker (17 cm) branded "DNH" made in Norway. Connector for second speaker (marked 2.H.P. = haut-parleur).

    Wavebands:

    • LW: 140 - 350 kHz
    • MW: 515 - 1620 kHz
    • FM 86,5 - 100 MHz

    Available in two colors: brown or ivory.

    See also similar model Emud Favorit 62.

  • Net weight (2.2 lb = 1 kg)
  • 4.2 kg / 9 lb 4 oz (9.251 lb)
  • Price in first year of sale
  • 3,450.00 BEF
  • Author
  • Model page created by Jozef Brughmans †. See "Data change" for further contributors.
