Radiobell Favori 116A
Bell Telephone Mfg. Co. (Radiobell); Antwerp
- Country
- Belgium
- Manufacturer / Brand
- Bell Telephone Mfg. Co. (Radiobell); Antwerp
- Year
- 1960 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 123016
-
- Brand: Radiobell
- Number of Tubes
- 5
- Number of Transistors
- Semiconductors
- Tr.Gl.=Metal-rectif.
- Main principle
- Superheterodyne (common); Export model
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110-130; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Radiobell Favori 116A - Bell Telephone Mfg. Co.
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 330 x 200 x 165 mm / 13 x 7.9 x 6.5 inch
- Notes
-
English lettering on the dial scale (Off, P.U., M, L, FM). Oval speaker (17 cm) branded "DNH" made in Norway. Connector for second speaker (marked 2.H.P. = haut-parleur).
Wavebands:
- LW: 140 - 350 kHz
- MW: 515 - 1620 kHz
- FM 86,5 - 100 MHz
Available in two colors: brown or ivory.
See also similar model Emud Favorit 62.
- Net weight (2.2 lb = 1 kg)
- 4.2 kg / 9 lb 4 oz (9.251 lb)
- Price in first year of sale
- 3,450.00 BEF
- Author
- Model page created by Jozef Brughmans †. See "Data change" for further contributors.
