Super-Inductance Radiola 425A

Super-Inductance Radiola 425A; Radiola marque (ID = 549496) Radio Super-Inductance Radiola 425A; Radiola marque (ID = 524812) Radio
Super-Inductance Radiola 425A; Radiola marque (ID = 239324) Radio Super-Inductance Radiola 425A; Radiola marque (ID = 524813) Radio
Super-Inductance Radiola 425A; Radiola marque (ID = 524814) Radio Super-Inductance Radiola 425A; Radiola marque (ID = 524815) Radio
Super-Inductance Radiola 425A; Radiola marque (ID = 524816) Radio Super-Inductance Radiola 425A; Radiola marque (ID = 549175) Radio
Super-Inductance Radiola 425A; Radiola marque (ID = 549176) Radio Super-Inductance Radiola 425A; Radiola marque (ID = 549177) Radio
Use red slider bar for more.
Super-Inductance Radiola 425A; Radiola marque (ID = 549496) Radio
Radiola marque: Super-Inductance Radiola 425A [Radio] ID = 549496 613x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Super-Inductance Radiola 425A, Radiola (marque)

Country:  France
Manufacturer / Brand:  Radiola (marque)
Brand

SFER
Year: 1932 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: TE52 TE52 TE24 TC43 V80
Main principle TRF without regeneration
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Magnetic loudspeaker (reed) generic. / Ø 28 cm = 11 inch
Power out
from Radiomuseum.org Model: Super-Inductance Radiola 425A - Radiola marque
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 455 x 540 x 203 mm / 17.9 x 21.3 x 8 inch
Notes

Haut-parleur type 2300.

Lampes de rechange: E452T, E452T, E424 ou E424N, C443, 506.

Mëme châssis radio que Radiola RA426A.

Net weight (2.2 lb = 1 kg) 12.3 kg / 27 lb 1.5 oz (27.093 lb)
Source of data -- Original prospect or advert
Literature/Schematics (1) Le grand livre de la TSF (Doctsf Ref 2864)
Literature/Schematics (3) Le Guide du Collectionneur TSF Biraud/Foster, Vol. II (page 349)

Model page created by John Koster. See "Data change" for further contributors.
