• Country
• France

• Manufacturer / Brand
• Radiola (marque)

• Year
• 1933/1934

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 102028

• • Brand: SFER

• Number of Tubes
• 5

• Valves / Tubes
• TE52 TE52 TE44 TC43 V80

• Main principle
• TRF without regeneration; 2 AF stage(s)

• Tuned circuits
• 4 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Super-Inductance de Luxe 445A - Radiola marque

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Dimensions (WHD)
• 420 x 490 x 270 mm / 16.5 x 19.3 x 10.6 inch

• Notes

• Super-inductance. Anti-fading. HP type 2159.

  Équvalent au Philips 634A.

• Price in first year of sale
• 2,980.00 FRF

• Source of data
• -- Original prospect or advert

• Mentioned in
• -- Original prospect or advert (Le Progrès de la Somme, 25.12.1933)

• Literature/Schematics (3)
• Le Guide du Collectionneur TSF Biraud/Foster, Vol. II (page 349)

• Author
• Model page created by John Koster. See "Data change" for further contributors.
