Miniature RA62T

Miniature RA62T; Radiola marque (ID = 1499849) Radio

Miniature RA62T; Radiola marque (ID = 1636360) Radio

Miniature RA62T; Radiola marque (ID = 1636361) Radio

Miniature RA62T; Radiola marque (ID = 1636362) Radio

Miniature RA62T; Radiola marque (ID = 1636366) Radio
Miniature RA62T; Radiola marque (ID = 820930) Radio Miniature RA62T; Radiola marque (ID = 820931) Radio
Miniature RA62T; Radiola marque (ID = 820932) Radio Miniature RA62T; Radiola marque (ID = 820933) Radio
Miniature RA62T; Radiola marque (ID = 1828721) Radio Miniature RA62T; Radiola marque (ID = 1828722) Radio
Use red slider bar for more.
Miniature RA62T; Radiola marque (ID = 820930) Radio
Radiola marque: Miniature RA62T [Radio] ID = 820930 933x566
Select picture or schematic to display from thumbnails on the right and click for download.
For model Miniature RA62T, Radiola (marque)

Country:  France
Manufacturer / Brand:  Radiola (marque)
Brand

SFER
Year: 1963/1964 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: OC44 OC45 OC45 OC75 OC71 OC71 OA79
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Dry Batteries / 1 x 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 cm = 2.4 inch
Power out
from Radiomuseum.org Model: Miniature RA62T - Radiola marque
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 143 x 81 x 33 mm / 5.6 x 3.2 x 1.3 inch
Notes

6 transistors + 1 diode. Prise pour écouteur.

Présentation: anthracite, ivoire, ou capucine. Livré sous étui.

Mentioned in Le grand livre de la TSF (Doctsf Ref 24370)
Literature/Schematics (1) -- Original prospect or advert
Literature/Schematics (2) -- Schematic

Model page created by John Koster. See "Data change" for further contributors.
