Maalesender MS12b

Maalesender MS12b; Radiometer; (ID = 235368) Equipment Maalesender MS12b; Radiometer; (ID = 235405) Equipment
Maalesender MS12b; Radiometer; (ID = 235406) Equipment Maalesender MS12b; Radiometer; (ID = 235407) Equipment
Maalesender MS12b; Radiometer; (ID = 235411) Equipment Maalesender MS12b; Radiometer; (ID = 235413) Equipment
Use red slider bar for more.
Maalesender MS12b; Radiometer; (ID = 235368) Equipment
Radiometer;: Maalesender MS12b [Equipment] ID = 235368 889x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Maalesender MS12b, Radiometer; Copenhagen:
MS 12b Front

Country:  Denmark
Manufacturer / Brand:  Radiometer; Copenhagen
Year: 1942 ? Category: Service- or Lab Equipment
Valves / Tubes 4: 4687 EBL21 EL2 EZ2
schematic requested
Tuned circuits 1 AM circuit(s)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 110; 240 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Maalesender MS12b - Radiometer; Copenhagen
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 370 x 285 x 200 mm / 14.6 x 11.2 x 7.9 inch
Notes Signal generator, six frequency ranges covering 100 kHz - 31 MHz; internal 400-Hz-AM-Modulator, 30 %.
Net weight (2.2 lb = 1 kg) 9 kg / 19 lb 13.2 oz (19.824 lb)
Source of data - - Data from my own collection

Model page created by Juhani Makivuoti † 21.09.13. See "Data change" for further contributors.
