• Country
• Austria

• Manufacturer / Brand
• Radione (RADIO Nikolaus Eltz); Wien

• Year
• 1955

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 155984

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• DK96 DF96 DAF96 DL96

• Number of Transistors

• Semiconductors
• Tr.Gl.=Metal-rectif.

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Line / Batteries (any type) / 110; 125; 150; 200; 220; 240 / 5 x 1,5 & 90 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16.5 cm = 6.5 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: 436A - Radione RADIO Nikolaus Eltz;

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 390 x 265 x 190 mm / 15.4 x 10.4 x 7.5 inch

• Notes
• Typenbezeichnung AB nicht gesichert. Netz/Batterieumschalter auf der Rückseite.

• Author
• Model page created by Hannes Wurnitsch. See "Data change" for further contributors.
