Radione RADIO: R41T [Radio] ID = 22391 713x647
Select picture or schematic to display from thumbnails on the right and click for download.
For model R41T, Radione (RADIO Nikolaus Eltz); Wien:
Radione R41T

Country:  Austria
Manufacturer / Brand:  Radione (RADIO Nikolaus Eltz); Wien
Year: 1963/1964 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7: AF117 AF117 AF117 OC71 AC125 AC127 AC132 OA79
Main principle Superheterodyne (common); ZF/IF 452 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 2x4,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out
from Radiomuseum.org Model: R41T - Radione RADIO Nikolaus Eltz;
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 240 x 160 x 80 mm / 9.4 x 6.3 x 3.1 inch
Net weight (2.2 lb = 1 kg) 1.3 kg / 2 lb 13.8 oz (2.863 lb)
Price in first year of sale 865.00 öS
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Literature/Schematics (1) -- Original-techn. papers.
Picture reference Das Modell ist im «Radiokatalog» (Erb) abgebildet.


All listed radios etc. from Radione (RADIO Nikolaus Eltz); Wien
Here you find 513 models, 356 with images and 319 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Radione RADIO: R41T
Threads: 1 | Posts: 1
Hits: 1955     Replies: 0
radione: R41T;
Gerhard Heigl
05.Aug.03
  1 Gehäuse: Kunststoff, Transistoren: 3x AF117, OC71, AC125, AC127/132.
