R44T Flugfunk

R44T; Radione RADIO (ID = 2150240) Radio R44T; Radione RADIO (ID = 2150242) Radio
R44T; Radione RADIO (ID = 2150243) Radio R44T; Radione RADIO (ID = 1793816) Radio
R44T; Radione RADIO (ID = 1793818) Radio R44T; Radione RADIO (ID = 1793821) Radio
R44T; Radione RADIO (ID = 1793824) Radio R44T; Radione RADIO (ID = 1795457) Radio
Use red slider bar for more.
R44T; Radione RADIO (ID = 2150240) Radio
Radione RADIO: R44T [Radio] ID = 2150240 1400x1207
Select picture or schematic to display from thumbnails on the right and click for download.
For model R44T Flugfunk, Radione (RADIO Nikolaus Eltz); Wien

Country:  Austria
Manufacturer / Brand:  Radione (RADIO Nikolaus Eltz); Wien
Year: 1962/1963 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9:
Main principle Superheterodyne (common); ZF/IF 452/10420 kHz
Tuned circuits 8 AM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Dry Batteries / 2 × 4,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 11 cm = 4.3 inch
Power out
from Radiomuseum.org Model: R44T [Flugfunk] - Radione RADIO Nikolaus Eltz;
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 240 x 160 x 80 mm / 9.4 x 6.3 x 3.1 inch
Notes

Wie R44T, jedoch anstelle von UKW-Rundfunk Flugfunkbereich 117-137 MHz.

Net weight (2.2 lb = 1 kg) 1.5 kg / 3 lb 4.9 oz (3.304 lb)
Mentioned in RADIOBOTE, Österr. (Heft 2/2006, S.17 f, Gerätebeschreibung)

Model page created by Bernd P. Kieck. See "Data change" for further contributors.
