National VS 59-663

National VS 59-663; Radio Popular, (ID = 1278419) Television

National VS 59-663; Radio Popular, (ID = 1278421) Television

National VS 59-663; Radio Popular, (ID = 1276257) Television

National VS 59-663; Radio Popular, (ID = 1276258) Television

National VS 59-663; Radio Popular, (ID = 1276259) Television
Use red slider bar for more.
National VS 59-663; Radio Popular, (ID = 1278419) Television
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Romania
Manufacturer / Brand:  Radio Popular, Bucharest
Year: 1966 Category: Television Receiver (TV) or Monitor
Valves / Tubes 16: A59-12W/2 4GK5 7GS7 EF80 EF80 EF183 EF184 ECL80 8A8 PCL82 12BY7A 18GV8 PL36 30AE3 DY86
Semiconductors (the count is only for transistors) OA91
Main principle Superheterodyne (common)
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC) / 120; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 2 W (unknown quality)
from Radiomuseum.org Model: National VS 59-663 - Radio Popular, Bucharest
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 722 x 515 x 250 mm / 28.4 x 20.3 x 9.8 inch
Notes Power consuption: 170VA
IF picture: 38MHz
IF audio I: 31.5 MHz
IF audio II: 6.5 MHz
Aerial impedance: 75/300 Ohm
CRT tube: A59-12 W/2, 110 degree
Picture size: 489x385 mm
Horizontal deflection: 450 lines
Net weight (2.2 lb = 1 kg) 29 kg / 63 lb 14 oz (63.877 lb)
Mentioned in Scheme de Televizoare Magnetofoane, Picupuri Ed.2 1976

Model page created by Adalbert Blenessy. See "Data change" for further contributors.
