For model 620, Radiotechna, spol. s r. o., Praha-Prelouc:
Telefunken 620

Country:  Czechoslovakia
Manufacturer / Brand:  Radiotechna, spol. s r. o., Praha-Prelouc
alternative name

Kresl & spol, CS
Brand
Telefunken Praha
Year: 1933/1934 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: RENS1264 REN904 RENS1264 RENS1264 REN924 RENS1374d RGN1064
Main principle Superhet with RF-stage
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110 - 240 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: 620 - Radiotechna, spol. s r. o.,
Material Bakelite case
Dimensions (WHD) 425 x 520 x 267 mm / 16.7 x 20.5 x 10.5 inch
Notes Case identical to German Telefunken 650.
Price in first year of sale 3'995.00 Kc
External source of data Reinhard Bittner

Model page created by a member from D. See "Data change" for further contributors.
