Country:  Canada
Manufacturer / Brand:  RCA Victor (International), Montreal
Year: 1937/1938 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 10: 6K7 6J7 6L7 6K7 6G5 6H6 6N7 6F6 6F6 5T4
Main principle Superhet with RF-stage; ZF/IF 460 kHz
Wave bands Broadcast plus 2 Short Wave bands.
Power type and voltage Alternating Current supply (AC) / 105-125 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm
Power out 10 W (unknown quality)
from Model: 810K - RCA Victor International,
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 26 x 42 x 12 inch / 660 x 1067 x 305 mm
Notes RCA 811K was simultaneously manufactured in Canada and USA.
Mentioned in RCA Vol 1 Page 254
Literature/Schematics (1) Radio College of Canada (RCC) (see CGE sheet 26 (F-107))

Model page created by Ashis Mukerjea. See "Data change" for further contributors.
