- Country
- Canada
- Manufacturer / Brand
- RCA Victor (International), Montreal
- Year
- 1938 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 295412
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 11
- Main principle
- Superhet with RF-stage; ZF/IF 455 kHz; 3 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast plus more than 2 Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 105 to 125 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 911KG - RCA Victor International,
- Shape
- Console with Push Buttons.
- Notes
-
The Canadian RCA-Victor model 911KG is an 11-tube console radio with pushbutton tuning and tuning eye tube. This is the larger and wider console cabinet (Grand) version of model 911K. Covers standard broadcast and shortwave in several ranges. Requires an external wire antenna.
- Literature/Schematics (1)
- - - Manufacturers Literature (RCA Service Manual (Montreal, Canada))
- Author
- Model page created by Tom Seeger. See "Data change" for further contributors.
