A672X

A672X ; RCA Victor (ID = 2305110) Car Radio
Use red slider bar for more.
A672X ; RCA Victor (ID = 2305110) Car Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Canada
Manufacturer / Brand:  RCA Victor (International), Montreal
Year: 1956 ? Category: Car Radio, perhaps also + sound player/recorder
Valves / Tubes 6: 12BA6 12BE6 12BA6 12AV6 12AQ5 12X4
Main principle Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: A672X - RCA Victor International,
Material Metal case
Shape Chassis only or for «building in»
Notes

The RCA-Victor model A672X is a 6-tube car radio with vibrator type B+ supply. Same as model A672 but with 12V tubes and vibrator.

Literature/Schematics (1) Radio College of Canada (RCC) (1957 Supplement 40)

Model page created by Tom Seeger. See "Data change" for further contributors.
