B64 ; RCA Victor (ID = 558884) Radio
RCA Victor: B64 [Radio] ID = 558884 540x592
Select picture or schematic to display from thumbnails on the right and click for download.
For model B64, RCA Victor (International), Montreal

Country:  Canada
Manufacturer / Brand:  RCA Victor (International), Montreal
Year: 1941 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 1A7G 1N5G 1H5G 1C5G
Main principle Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Storage and/or dry batteries / 2 x 45, 1 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out 0.115 W (0.26 W max.)
from Radiomuseum.org Model: B64 - RCA Victor International,
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 12.5 x 14.25 x 7.5 inch / 318 x 362 x 191 mm
Notes

Current consumption: A battery - 0.25 ampere, B batteries -  9.6 Ma

Net weight (2.2 lb = 1 kg) 3.5 kg / 7 lb 11.3 oz (7.709 lb)
Source of data - - Manufacturers Literature
Mentioned in Cathedral & Tombstone Radios (page 225.)

Model page created by Ashis Mukerjea. See "Data change" for further contributors.
