• Year
  • 1936 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 295175

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 4
  • Main principle
  • Superheterodyne (common); ZF/IF 460 kHz; 2 AF stage(s)
  • Tuned circuits
  • 4 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Alternating Current supply (AC) / 105 to 125 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • from Radiomuseum.org
  • Model: T4-2 - RCA Victor International,
  • Notes
  • The Canadian RCA-Victor model T4-2 is a 4-tube broadcast only radio. Requires an external wire antenna.

  • Literature/Schematics (1)
  • - - Manufacturers Literature (RCA Victor Service Manual (Montreal, Canada))
  • Author
  • Model page created by Tom Seeger. See "Data change" for further contributors.
