Europa Standard Combination ; Reico Radio, Max (ID = 1323940) Radio
Reico Radio, Max: Europa Standard Combination [Radio] ID = 1323940 922x692
Select picture or schematic to display from thumbnails on the right and click for download.
For model Europa Standard Combination, Reico Radio, Max Reinhardt & Co.; Berlin

Country:  Germany
Manufacturer / Brand:  Reico Radio, Max Reinhardt & Co.; Berlin
Year: 1933/1934 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: RENS1204 RENS1204 RES164 RGN504
Main principle TRF with regeneration; 1 AF stage(s); Anode bend detection
Tuned circuits 2 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 150; 220 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Europa Standard Combination - Reico Radio, Max Reinhardt &
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 365 x 460 x 195 mm / 14.4 x 18.1 x 7.7 inch
Notes

Zweiteilige Kombination bestehend aus Europa Standard W und Lautsprecher. Der Lautsprecher ist von der Maserung passend zum Gerät ausgewählt.

Der Lautsprecher kann auch separat aufgestellt werden.

Nur für Wechselstrom lieferbar. Preis für den Röhrensatz RM 53,80.

Net weight (2.2 lb = 1 kg) 9.2 kg / 20 lb 4.2 oz (20.264 lb)
Price in first year of sale 135.00 RM
Mentioned in -- Original prospect or advert

Model page created by Timo Rantasaari. See "Data change" for further contributors.
