Feinabstimmgerät ED 30 EU 39
Use red slider bar for more.
Rohde & Schwarz, PTE: Feinabstimmgerät ED 30 EU 39 [Converter] ID = 1185503 670x933
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
|
alternative name
|
Messgerätebau Memmingen || Physikalisch-Technisches Entwicklungslabor Dr. Rohde & Dr. Schwarz | ||||
|---|---|---|---|---|---|
| Year: 1964 ? | Category: Pre-stage (adaptor for SW/FM/VHF/UHF incl. built-in), Frequency converter | ||||
| Valves / Tubes | unknown_Tube | ||||
| Semiconductors (the count is only for transistors) | Semiconductors present. AF115 |
| Main principle | RF Converter/Adapter (not voltage converter) |
|---|---|
| Wave bands | Wave Bands given in the notes. |
| Details | Converter |
| Power type and voltage | Alternating Current supply (AC) / 115-125; 220-235 Volt |
| Loudspeaker | - For headphones or amp. |
| Power out | |
| from Radiomuseum.org | Model: Feinabstimmgerät ED 30 EU 39 - Rohde & Schwarz, PTE; München |
| Material | Metal case |
| Shape | Tablemodel, high profile (upright - NOT Cathedral nor decorative). |
| Notes | Rohde & Schwarz Feinabstimmgerät ED 30, EU 39; Für ED 80 UHF Empfänger. ~100 - 157 MHz. 1.65 MHz ZF Eingang. 21.6 - 36.6 MHz Ausgänge, AFC, Hörer Ausgang. |
| Net weight (2.2 lb = 1 kg) | 14 kg / 30 lb 13.4 oz (30.837 lb) |
