RC-Generator SRN (BN 4084) FNr. 1054/5
Rohde & Schwarz, PTE; München
- Country
- Germany
- Manufacturer / Brand
- Rohde & Schwarz, PTE; München
- Year
- 1957 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 281809
-
- alternative name: Messgerätebau Memmingen || Physikalisch-Technisches Entwicklungslabor Dr. Rohde & Dr. Schwarz
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Power type and voltage
- Alternating Current supply (AC) / 115; 125; 220 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: RC-Generator SRN [FNr. 1054/5] - Rohde & Schwarz, PTE; München
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 470 x 275 x 260 mm / 18.5 x 10.8 x 10.2 inch
- Notes
-
Siehe auch ähnliches Gerät: SRN (BN 4084) [FNr. M841/69]
R&S-Normkasten der Größe 46
Eingebaute Glühlampe: Osram 230V 9W
- Net weight (2.2 lb = 1 kg)
- 18 kg / 39 lb 10.4 oz (39.648 lb)
- Author
- Model page created by Michael Sors. See "Data change" for further contributors.
