• Country
• Germany

• Manufacturer / Brand
• Rohde & Schwarz, PTE; München

• Year
• 1938 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 113910

• • alternative name: Messgerätebau Memmingen || Physikalisch-Technisches Entwicklungslabor Dr. Rohde & Dr. Schwarz

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• KB2

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Dry Batteries / 3 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Wooden case

• from Radiomuseum.org
• Model: Resonanz-Frequenzmesser WAD - Rohde & Schwarz, PTE; München

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 152 x 128 x 192 mm / 6 x 5 x 7.6 inch

• Notes
• Resonanz-Frequenzmesser für Meterwellen.
  Bereich: 20 bis 300 MHz, in fünf Wellenbereiche unterteilt.
  Das Gerät wurde auch mit einer in Meter beschrifteten Skala geliefert (1 bis 15 m).

• Net weight (2.2 lb = 1 kg)
• 1.7 kg / 3 lb 11.9 oz (3.744 lb)

• Price in first year of sale
• 300.00 RM

• Mentioned in
• - - Data from my own collection

• Author
• Model page created by a member from D. See "Data change" for further contributors.
