• Country
• Germany

• Manufacturer / Brand
• SABA; Villingen

• Year
• 1962

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 72943

• • Brand: Schwer & Söhne, GmbH

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 9

• Valves / Tubes
• EC92 EC92 ECH81 EBF89 EM84 ECC83 EC92 EL95 EL95

• Main principle
• Superheterodyne (common); ZF/IF 460/6750 kHz

• Wave bands
• Broadcast, 2 Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 115 Volt

• Loudspeaker
• 4 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: 200-Stereo 11 - SABA; Villingen

• Shape
• Tablemodel with Push Buttons.

• Notes
• UKW Bereich 88 bis 108MHz, 2x KW: Marineband 1,55 - 4,3MHz und SW 5,8 - 18,9MHz. Exportvariante des Freudenstadt 11 Stereo.

• Source of data
• -- Schematic

• Author
• Model page created by Iven Müller. See "Data change" for further contributors.
