• Country
• Germany

• Manufacturer / Brand
• SABA; Villingen

• Year
• 1950/1951

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 219527

• • Brand: Schwer & Söhne, GmbH

• Number of Tubes
• 11

• Valves / Tubes
• EF41 ECH42 EAF42 EAF42 EM4 EL41 AZ11 ECH42 EF42 EF42 EQ80

• Main principle
• Superhet with RF-stage; ZF/IF 472 kHz

• Tuned circuits
• 9 AM circuit(s)     8 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, more than 2 x SW plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 27 cm = 10.6 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Freiburg WUS - SABA; Villingen

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 586 x 422 x 258 mm / 23.1 x 16.6 x 10.2 inch

• Notes
• Drei KW-Bereiche; das Gerät entspricht dem Freiburg W zuzüglich eingebautem UKW Superhetvorsatz UKW-S.

• Price in first year of sale
• 490.00 DM

• Source of data
• Kat.d. Rundf.Gr.Handel 1950/51

• Author
• Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
