Schauinsland T3600 Color

Schauinsland T3600 Color; SABA; Villingen (ID = 867381) Television
Schauinsland T3600 Color; SABA; Villingen (ID = 866679) Television
Use red slider bar for more.
Schauinsland T3600 Color; SABA; Villingen (ID = 866679) Television
SABA; Villingen: Schauinsland T3600 Color [Television] ID = 866679 933x889
Select picture or schematic to display from thumbnails on the right and click for download.
For model Schauinsland T3600 Color, SABA; Villingen:
Quelle: Prospekt

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1970/1971 Category: Television Receiver (TV) or Monitor
Valves / Tubes 11: PCL805 PCF802 PY500 PL509 PC92 PC92 EF80 EF183 PL802 PL95 A63-100X
Semiconductors (the count is only for transistors) 31:
Main principle Super-Heterodyne (Super in general)
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Schauinsland T3600 Color - SABA; Villingen
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 795 x 525 x 575 mm / 31.3 x 20.7 x 22.6 inch
Notes 3 ICs.
Wellenbereiche: VHF-Kanäle 2-12, UHF-Kanäle 21-60.
Siehe auch Schauinsland T2600 Color
Net weight (2.2 lb = 1 kg) 45 kg / 99 lb 1.9 oz (99.119 lb)
Source of data -- Original-techn. papers.

Model page created by Arpad Roth † 27.3.17. See "Data change" for further contributors.
