Universum 6 (U6) ohne Netzteil

Universum 6 ; SABA; Villingen (ID = 5596) Radio
Universum 6 ; SABA; Villingen (ID = 62895) Radio Universum 6 ; SABA; Villingen (ID = 1621205) Radio
Universum 6 ; SABA; Villingen (ID = 1621213) Radio Universum 6 ; SABA; Villingen (ID = 1746860) Radio
Universum 6 ; SABA; Villingen (ID = 2002706) Radio Universum 6 ; SABA; Villingen (ID = 2002707) Radio
Universum 6 ; SABA; Villingen (ID = 2002708) Radio Universum 6 ; SABA; Villingen (ID = 2002709) Radio
Universum 6 ; SABA; Villingen (ID = 2002710) Radio Universum 6 ; SABA; Villingen (ID = 2002711) Radio
Use red slider bar for more.
Universum 6 ; SABA; Villingen (ID = 62895) Radio
SABA; Villingen: Universum 6 [Radio] ID = 62895 651x402
Select picture or schematic to display from thumbnails on the right and click for download.
For model Universum 6 (U6) ohne Netzteil, SABA; Villingen

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1928–1930 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: RE084 RE074 RE074 RE084 RE084 RE134
Main principle TRF without regeneration; 3 Special; 2 AF stage(s); Neutrodyne
Tuned circuits 3 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Storage and/or dry batteries / 200+4 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Universum 6 [ohne Netzteil] - SABA; Villingen
Material Wooden case
Dimensions (WHD) 480 x 240 x 290 mm / 18.9 x 9.4 x 11.4 inch
Notes ape.Vorstufe; gek.Drehkos [560]
Price in first year of sale 280.00 RM +
Collectors' prices
Source of data Radio-Diehr, Berlin, 1928/1929 / Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Lange + FS-Bestückungstabellen
Mentioned in Saba-Diplomarbeit
