For model UW 306, SABA; Villingen

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1963 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH81 EF89 EBC81 EL95 EM84
Semiconductors (the count is only for transistors) E250C85
Main principle Superheterodyne (common); Export model
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 117-220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 21 cm = 8.3 inch
Power out 2 W (2.5 W max.)
from Radiomuseum.org Model: UW 306 - SABA; Villingen
Material Bakelite or Plastics (type unknown)
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 435 x 270 x 225 mm / 17.1 x 10.6 x 8.9 inch
Notes

Siehe auch das inländische Modell Saba Königsfeld 14 mit anderen Wellenbereichen und Holzgehäuse.

SW1: 15...26 MHz
SW2: 7...15 MHz
SW3: 2,3...7 MHz
M: 520...1620 kHz

Net weight (2.2 lb = 1 kg) 7 kg / 15 lb 6.7 oz (15.419 lb)
