Ural {Урал} 47M {47М}

Sarapoul Orjonikidze Radio Works

  • Year
  • 1947
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 110427

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 467 kHz
  • Tuned circuits
  • 4 AM circuit(s)
  • Wave bands
  • Broadcast, Long Wave and Short Wave.
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 127; 220 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • Power out
  • 4 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Ural {Урал} 47M {47М} - Sarapoul Orjonikidze Radio
  • Shape
  • Tablemodel, with any shape - general.
  • Mentioned in
  • E.A. Levitin "Radio sets" Moscow 1960
  • Author
  • Model page created by Zenonas Langaitis. See "Data change" for further contributors.
