110C
Savigliano, Officine: 110C [Radio] ID = 2630627 1200x740
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1940/1941 | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 6: 6A8 6K7 6Q7 6V6 6E5 5Y3 |
|---|
| Main principle | Superheterodyne (common) |
|---|---|
| Tuned circuits | 6 AM circuit(s) |
| Wave bands | Broadcast plus 2 Short Wave bands. |
| Details | |
| Power type and voltage | Alternating Current supply (AC) / 110-220 Volt |
| Loudspeaker | Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 18 cm = 7.1 inch |
| Power out | 4 W (unknown quality) |
| from Radiomuseum.org | Model: 110C - Savigliano, Officine di, SA; |
| Material | Wooden case |
| Shape | Tablemodel, low profile (big size). |
| Dimensions (WHD) | 542 x 315 x 290 mm / 21.3 x 12.4 x 11.4 inch |
| Notes | Soprannominato "Ovone" per la sua forma ovale. Gamme d'onda: medie, corte, cortissime. Called "Ovone" (big egg) owing to its shape. |
| Net weight (2.2 lb = 1 kg) | 12.5 kg / 27 lb 8.5 oz (27.533 lb) |
| Source of data | Guida Pratica Antique Radio II (2000) |
| Mentioned in | -- Original prospect or advert (L'antenna, n.17, settembre 1940) |
Model page created by Rino Ferro † 2008. See "Data change" for further contributors.
