• Country
• Belgium

• Manufacturer / Brand
• SBR Société Belge Radio-Electrique, Bruxelles

• Year
• 1935/1936

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 31055

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 6A7 6D6 75 43 25Z5

• Main principle
• Superheterodyne (common); ZF/IF 123 kHz

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• AC/DC-set / 110; 130; 140; 220; 245 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 19 cm = 7.5 inch

• Power out
• 2.2 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Ondolinette 364U - SBR Société Belge Radio-

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Dimensions (WHD)
• 340 x 430 x 210 mm / 13.4 x 16.9 x 8.3 inch

• Net weight (2.2 lb = 1 kg)
• 9.4 kg / 20 lb 11.3 oz (20.705 lb)

• Price in first year of sale
• 1,650.00 BFr

• Mentioned in
• Manuel de la Radio 1940, van Cortenberghe

• Author
• Model page created by Bruno Brasseur. See "Data change" for further contributors.
