- Country
- Belgium
- Manufacturer / Brand
- SBR Société Belge Radio-Electrique, Bruxelles
- Year
- 1964
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 31093
from radiomuseum Olen
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 3
- Main principle
- Audio-Amplification
- Details
- Tape Recorder
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 205; 220; 245 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 3 W (unknown quality)
- Material
- Various materials
- from Radiomuseum.org
- Model: B1 - SBR Société Belge Radio-
- Dimensions (WHD)
- 340 x 305 x 165 mm / 13.4 x 12 x 6.5 inch
- Notes
-
- Tape recorder with 2 speeds: 9.5 and 4.75 cm/sec.
- Reel diameter: 15 cm.
- Author
- Model page created by Bruno Brasseur. See "Data change" for further contributors.
