• Country
• Germany

• Manufacturer / Brand
• Schaleco - Schackow, Leder und Co; Berlin

• Year
• 1928/1929

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 6388

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• RE074n RE074n RE074n RE084 RE034 RE134

• Main principle
• TRF with regeneration; Neutrodyne

• Tuned circuits
• 4 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Storage and/or dry batteries

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Wooden case

• from Radiomuseum.org
• Model: Standard Neutro IV - Schaleco - Schackow, Leder und

• Shape
• Tablemodel, Box - most often with Lid (NOT slant panel).

• Dimensions (WHD)
• 852 x 242 x 328 mm / 33.5 x 9.5 x 12.9 inch

• Notes
• Bausatz, 4 Abst.-Kr. [5-105B]

• Net weight (2.2 lb = 1 kg)
• 20.3 kg / 44 lb 11.4 oz (44.714 lb)

• Source of data
• Radio Schnorr 1929 / Radiokatalog Band 1, Ernst Erb

• Circuit diagram reference
• Röhren in FS-Bestückungstabellen

• Mentioned in
• Radio Nostalgie

• Picture reference
• Das Gerät ist im Doppelband "Historische Radios" von Günther Abele abgebildet.
