Model 41 ECH35

Model 41; Ernsmiths Scharnberg (ID = 1376708) Radio Model 41; Ernsmiths Scharnberg (ID = 1376709) Radio
Model 41; Ernsmiths Scharnberg (ID = 1376710) Radio
Use red slider bar for more.
Model 41; Ernsmiths Scharnberg (ID = 1376708) Radio
Ernsmiths Scharnberg: Model 41 [Radio] ID = 1376708 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Model 41 ECH35, Ernsmiths (Scharnberg Strauss); Adelaide

Country:  Australia
Manufacturer / Brand:  Ernsmiths (Scharnberg Strauss); Adelaide
Year: 1947 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: ECH35 EBF35 6V6GT 5Y3G
Main principle Superheterodyne (common)
Wave bands Broadcast only (MW).
Details
Power type and voltage Alternating Current supply (AC) / 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out
from Radiomuseum.org Model: Model 41 [ECH35] - Ernsmiths Scharnberg Strauss;
Material Bakelite case
Shape Tablemodel without push buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 270 x 175 x 170 mm / 10.6 x 6.9 x 6.7 inch
Notes

A later Model 41 exists with the following valves: 6AN7 6SF7 6M5 5Y3GT

Net weight (2.2 lb = 1 kg) 5 kg / 11 lb 0.2 oz (11.013 lb)
Price in first year of sale 17.00 Guineas AU

Model page created by Harold Norrie. See "Data change" for further contributors.
