Multinorm Luxus 6059 473041/473043/473141/473143

Schaub und Schaub-Lorenz

  • Year
  • 1965/1966
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 327247

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 20
  • Number of Transistors
  • 2
  • Main principle
  • Superhet with RF-stage; ZF/IF 38900 kHz; 2 AF stage(s)
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • 2 Loudspeakers
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Multinorm Luxus 6059 473041/473043/473141/473143 - Schaub und Schaub-Lorenz
  • Shape
  • Tablemodel, low profile (big size).
  • Notes
  • Schaub-Lorenz, Multinorm Luxus 6059

    Gehäuse für Typ 473141/041 hell
    Gehäuse für Typ 473143/043 dunkel

  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
