• Country
• France

• Manufacturer / Brand
• Schneider (Frères, Radio-Télévision); Paris, Ivry / Seine

• Year
• 1959

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 71025

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• ECH81 or 6AJ8 EBF80 or 6N8 6AU6 6AQ5 EM81 EZ80 or 6V4

• Main principle
• Superheterodyne (common); ZF/IF 480 kHz

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and 2 x Short Wave.

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 110-245 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: Bolero AM 59 - Schneider Frères, Radio-

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 500 x 370 x 360 mm / 19.7 x 14.6 x 14.2 inch

• Notes

• Haut-parleur elliptique de 25 x 15 cm.

• External source of data
• Serge Laffont/Martin Renoth

• Author
• Model page created by Ernst Erb. See "Data change" for further contributors.
