Silvertone 1702
Sears, Roebuck & Co.; Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sears, Roebuck & Co.; Chicago (IL)
- Year
- 1934
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 227858
-
- Brand: Silvertone
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- TRF (Tuned-Radio-Frequency but use of regeneration unknown)
- Tuned circuits
- 2 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- AC/DC-set / Either AC 25 to 60 cycles, 90 to 125V or DC 90 to 125 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- from Radiomuseum.org
- Model: Silvertone 1702 - Sears, Roebuck & Co.; Chicago
- Notes
-
The Sears Silvertone 1702 is an AC operated 4 tube BC band receiver. Has 175 ohm resistance built into the line cord (Curtain Burner).
See details and summaries about Sears catalogs etc. This model was manufactured for Sears by Corona Radio and Television Corp., Chicago, Ill (Sears Manufacturer Source Number Code 104).
- Literature/Schematics (1)
- Silvertone Radios, Service Inf. 1928 thru 1936 (Page 324)
- Author
- Model page created by John Kusching. See "Data change" for further contributors.
