• Country
• Germany

• Manufacturer / Brand
• Sennheiser Electronic (Labor W); Wennebostel

• Year
• 1979

• Category
• Microphone or Pick-up element

• Radiomuseum.org ID
• 127250

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Details
• Other Combination - see Notes

• Power type and voltage
• Storage and/or dry batteries / 12 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Studio-Richtmikrofon MKH416T - Sennheiser Electronic Labor W;

• Shape
• Miscellaneous shapes - described under notes.

• Dimensions (WHD)
• 19 x 19 x 235 mm / 0.7 x 0.7 x 9.3 inch

• Notes
• HF-Kondensatormikrofon, Übertragungsbereich 40 bis 20000Hz, maximale Anschlußimpedanz 400Ohm.

• Net weight (2.2 lb = 1 kg)
• 0.2 kg / 0 lb 7 oz (0.441 lb)

• Mentioned in
• -- Original-techn. papers. (1979/1980)

• Author
• Model page created by Karlheinz Fischer. See "Data change" for further contributors.
