P61 Ch= C100-Late; Setchell Carlson, (ID = 1241095) Television
Setchell Carlson,: P61 Ch= C100-Late [Television] ID = 1241095 700x525
Select picture or schematic to display from thumbnails on the right and click for download.
For model P61 Ch= C100-Late, Setchell Carlson, Inc.; St.Paul (MN)

Country:  United States of America (USA)
Manufacturer / Brand:  Setchell Carlson, Inc.; St.Paul (MN)
Brand

Doraphone
Year: 1956 ? Category: Television Receiver (TV) or Monitor
Valves / Tubes 19: 6BQ7A or 6BC8 6AT8 or 6BR8 6BA6 6AU6 6AU6 6AU8 or 6AW8 6AU8 or 6AW8 6AU6 6T8 6AQ5 12AU7A 6V6GT 6AL5 12AU7A 6CU6 or 6BQ6GA 6AX4GT 1B3GT 5U4GB or 5U4GA 21ATP4
Main principle Superhet with RF-stage
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 60 cycles, 110-120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
Power out
from Radiomuseum.org Model: P61 Ch= C100-Late - Setchell Carlson, Inc.; St.
Material Wooden case
Shape Tablemodel, with any shape - general.
Notes

The Setchell-Carlson model P61 is a 21" b/w TV with US standard VHF Tuner channels 2 thru 13. Equipped with chassis "100 - late" and picture tube 21ATP4 .

Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Date 9-56, Set 329, Folder 12)

Model page created by Egon Penker. See "Data change" for further contributors.
