For model 31G, Siemens; D (S.& Halske / S. Electrogeräte):
Siemens 31G

Country:  Germany
Manufacturer / Brand:  Siemens; D (S.& Halske / S. Electrogeräte)
Year: 1930/1931 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3: RE034s RE034s RE134S
Main principle TRF with regeneration; 2 AF stage(s)
Tuned circuits 1 AM circuit(s)
Wave bands Broadcast and LongWave in ONE range.
Details
Power type and voltage Direct Current supply (DC) / 110-220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: 31G - Siemens; D S.& Halske / S.
Material Wooden case
Dimensions (WHD) 380 x 220 x 160 mm / 15 x 8.7 x 6.3 inch
Notes Halbkrf. «Riesenskala» [569]
Price in first year of sale 149.00 RM !
Source of data Katalog Radio-Zentrale Prohaska 1930/31 (dick) / Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Lange + FS-Bestückungstabellen
Mentioned in Funkgeschichte der GFGF (8756)
