• Country
• Germany

• Manufacturer / Brand
• Siemens (& Halske, -Schuckert Werke SSW, Electrogeräte); Berlin, München

• Year
• 1952 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 226132

• Number of Tubes
• 6

• Valves / Tubes
• EF41 ECH42 EAF42 EAF42 EM34 EL41

• Number of Transistors

• Semiconductors
• B250C90

• Main principle
• Superhet with RF-stage; Export model

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and more than two Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 110 - 240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 4 W (max.)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Gross-Super SH724W - Siemens & Halske, -Schuckert

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 600 x 400 x 280 mm / 23.6 x 15.7 x 11 inch

• Notes

• Siemens Gross-Super SH724W ist ein Exportmodell.

• Author
• Model page created by Bernhard Nagel. See "Data change" for further contributors.
