Neutro Rfe18

Neutro Rfe18; Siemens; D S.& (ID = 65615) Radio

Neutro Rfe18; Siemens; D S.& (ID = 341799) Radio
Neutro Rfe18; Siemens; D S.& (ID = 341727) Radio Neutro Rfe18; Siemens; D S.& (ID = 341738) Radio
Neutro Rfe18; Siemens; D S.& (ID = 342450) Radio Neutro Rfe18; Siemens; D S.& (ID = 341731) Radio
Neutro Rfe18; Siemens; D S.& (ID = 341732) Radio Neutro Rfe18; Siemens; D S.& (ID = 341733) Radio
Neutro Rfe18; Siemens; D S.& (ID = 341735) Radio Neutro Rfe18; Siemens; D S.& (ID = 341736) Radio
Neutro Rfe18; Siemens; D S.& (ID = 341737) Radio Neutro Rfe18; Siemens; D S.& (ID = 342449) Radio
Use red slider bar for more.
Neutro Rfe18; Siemens; D S.& (ID = 341727) Radio
Siemens; D S.&: Neutro Rfe18 [Radio] ID = 341727 925x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Neutro Rfe18, Siemens; D (S.& Halske / S. Electrogeräte)

Country:  Germany
Manufacturer / Brand:  Siemens; D (S.& Halske / S. Electrogeräte)
Year: 1927/1928 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: RE064 RE064 RE054 RE154
Main principle TRF with regeneration; 1 Special; 2 AF stage(s); Neutrodyne
Tuned circuits 2 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Storage and/or dry batteries / 2 or 4 & 1,5 & 6 & 100 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: Neutro Rfe18 - Siemens; D S.& Halske / S.
Material Wooden case, TUBES VISIBLE.
Shape Tablemodel, slant panel.
Dimensions (WHD) 440 x 295 x 230 mm / 17.3 x 11.6 x 9.1 inch
Notes Widerstandskopplung im NF-Verstärker, verbesserte Ausführung des Rfe10.
Röhrenbestückung für 2V Heizspannung: RE062 RE062 RE052 RE152
Für höhere Ausgangsleistung wurde RE354 oder RE352 (2V) empfohlen.
Net weight (2.2 lb = 1 kg) 8 kg / 17 lb 9.9 oz (17.621 lb)
Price in first year of sale 290.00 RM
Source of data Katalog Radio-Zentrale Prohaska 1928 / Radiokatalog Band 1, Ernst Erb
Literature/Schematics (1) -- Original-techn. papers.
Picture reference Eine Abbildung findet sich im Doppelband "Radio von gestern"
