Protos- Gleichrichter L1702

Protos- Gleichrichter L1702; Siemens; D S.& (ID = 1343018) Power-S

Protos- Gleichrichter L1702; Siemens; D S.& (ID = 1343027) Power-S
Protos- Gleichrichter L1702; Siemens; D S.& (ID = 58964) Power-S Protos- Gleichrichter L1702; Siemens; D S.& (ID = 58965) Power-S
Protos- Gleichrichter L1702; Siemens; D S.& (ID = 58966) Power-S Protos- Gleichrichter L1702; Siemens; D S.& (ID = 84763) Power-S
Protos- Gleichrichter L1702; Siemens; D S.& (ID = 455758) Power-S Protos- Gleichrichter L1702; Siemens; D S.& (ID = 521449) Power-S
Protos- Gleichrichter L1702; Siemens; D S.& (ID = 743901) Power-S Protos- Gleichrichter L1702; Siemens; D S.& (ID = 743902) Power-S
Protos- Gleichrichter L1702; Siemens; D S.& (ID = 1413983) Power-S Protos- Gleichrichter L1702; Siemens; D S.& (ID = 1413984) Power-S
Use red slider bar for more.
Protos- Gleichrichter L1702; Siemens; D S.& (ID = 58964) Power-S
Siemens; D S.&: Protos- Gleichrichter L1702 [Power-S] ID = 58964 802x585
Select picture or schematic to display from thumbnails on the right and click for download.
For model Protos- Gleichrichter L1702, Siemens; D (S.& Halske / S. Electrogeräte)

Country:  Germany
Manufacturer / Brand:  Siemens; D (S.& Halske / S. Electrogeräte)
Year: 1928–1933 Category: Power supply/conditioner or battery or charger
Semiconductors (the count is only for transistors) Tr.Gl.=Metal-rectif.
Wave bands - without
Details Power: Charger for A-Batteries
Power type and voltage Alternating Current supply (AC) / 200-250 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Protos- Gleichrichter L1702 - Siemens; D S.& Halske / S.
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 140 x 70 x 125 mm / 5.5 x 2.8 x 4.9 inch
Notes Ladegerät für 1-3 Zellen. Kupferoxydul-Trockengleichrichter.
Net weight (2.2 lb = 1 kg) 2 kg / 4 lb 6.5 oz (4.405 lb)
Price in first year of sale 28.00 RM
Source of data Unterlagen Deutsches R.Museum
Mentioned in Katalog Radio-Zentrale Prohaska 1932/33
Literature/Schematics (1) Siemens Preisliste 1929

Model page created by Hinrich Grensemann † 15.5.16. See "Data change" for further contributors.
