SM524

SM524; Siemens Italia; (ID = 257501) Radio

SM524; Siemens Italia; (ID = 580440) Radio

SM524; Siemens Italia; (ID = 580442) Radio

SM524; Siemens Italia; (ID = 580443) Radio
SM524; Siemens Italia; (ID = 426425) Radio SM524; Siemens Italia; (ID = 426426) Radio
SM524; Siemens Italia; (ID = 426427) Radio SM524; Siemens Italia; (ID = 1177333) Radio
Use red slider bar for more.
SM524; Siemens Italia; (ID = 426425) Radio
Siemens Italia;: SM524 [Radio] ID = 426425 900x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model SM524, Siemens Italia; Milano

Country:  Italy
Manufacturer / Brand:  Siemens Italia; Milano
Year: 1954 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCH42 UAF42 UAF42 UL41 UY41
Main principle Superheterodyne (common); ZF/IF 469 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 160; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: SM524 - Siemens Italia; Milano
Material Wooden case
Shape Tablemodel, low profile (big size).
Notes

Simile al modello S524.

Mentioned in Collezione di Schemi, Scuola Radio Elettra 1953 (pag. 156)

Model page created by Alessandro De Poi. See "Data change" for further contributors.
