Szuper 343 V
Siemens; Budapest: Szuper 343 V [Radio] ID = 1700079 700x525
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1943 | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 4: ECH4 EBF2 ECL11 AZ1 |
|---|
| Main principle | Superheterodyne (common) |
|---|---|
| Tuned circuits | 5 AM circuit(s) |
| Wave bands | Broadcast, Long Wave and Short Wave. |
| Details | |
| Power type and voltage | Alternating Current supply (AC) / 110-240 Volt |
| Loudspeaker | Permanent or electro-dynamic (moving coil), system not known yet. / Ø 16 cm = 6.3 inch |
| Power out | |
| from Radiomuseum.org | Model: Szuper 343 V - Siemens; Budapest |
| Material | Bakelite case |
| Shape | Tablemodel, with any shape - general. |
| Dimensions (WHD) | 395 x 270 x 200 mm / 15.6 x 10.6 x 7.9 inch |
| Source of data | - - Manufacturers Literature |
Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
