Turf RK41

Turf RK41; Siemens; D S.& (ID = 1085113) Radio

Turf RK41; Siemens; D S.& (ID = 1085114) Radio

Turf RK41; Siemens; D S.& (ID = 1085116) Radio

Turf RK41; Siemens; D S.& (ID = 1085118) Radio

Turf RK41; Siemens; D S.& (ID = 1085120) Radio

Turf RK41; Siemens; D S.& (ID = 1085121) Radio

Turf RK41; Siemens; D S.& (ID = 1085123) Radio

Turf RK41; Siemens; D S.& (ID = 1085124) Radio

Turf RK41; Siemens; D S.& (ID = 1085125) Radio

Turf RK41; Siemens; D S.& (ID = 1085122) Radio
Turf RK41; Siemens; D S.& (ID = 579426) Radio Turf RK41; Siemens; D S.& (ID = 579427) Radio
Turf RK41; Siemens; D S.& (ID = 526566) Radio
Use red slider bar for more.
Turf RK41; Siemens; D S.& (ID = 579426) Radio
Siemens; D S.&: Turf RK41 [Radio] ID = 579426 502x419
Select picture or schematic to display from thumbnails on the right and click for download.
For model Turf RK41, Siemens; D (S.& Halske / S. Electrogeräte)

Country:  Germany
Manufacturer / Brand:  Siemens; D (S.& Halske / S. Electrogeräte)
Year: 1963/1964 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: AF114 AF115 AF126 AF126 AF126 OC70 OC71 OC74 OC74
Main principle Superheterodyne (common); ZF/IF 460/6750 kHz
Tuned circuits 5 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Short Wave plus FM or UHF.
Details
Power type and voltage Dry Batteries / 2 × 4.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out 1 W (unknown quality)
from Radiomuseum.org Model: Turf RK41 - Siemens; D S.& Halske / S.
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 265 x 165 x 80 mm / 10.4 x 6.5 x 3.1 inch
Net weight (2.2 lb = 1 kg) 1.9 kg / 4 lb 3 oz (4.185 lb)
Price in first year of sale 202.00 DM
Source of data Handbuch VDRG 1963/1964 / Radiokatalog Band 1, Ernst Erb
Mentioned in Handbuch RFP 1963
