S242U

S242U; Siera; Belgien (ID = 20114) Radio

S242U; Siera; Belgien (ID = 20115) Radio

S242U; Siera; Belgien (ID = 1018350) Radio

S242U; Siera; Belgien (ID = 2553930) Radio

S242U; Siera; Belgien (ID = 2553931) Radio

S242U; Siera; Belgien (ID = 2553932) Radio

S242U; Siera; Belgien (ID = 2553933) Radio

S242U; Siera; Belgien (ID = 2553934) Radio

S242U; Siera; Belgien (ID = 2553935) Radio

S242U; Siera; Belgien (ID = 2553936) Radio
S242U; Siera; Belgien (ID = 731892) Radio S242U; Siera; Belgien (ID = 251113) Radio
Use red slider bar for more.
S242U; Siera; Belgien (ID = 731892) Radio
Siera; Belgien: S242U [Radio] ID = 731892 875x744
Select picture or schematic to display from thumbnails on the right and click for download.
For model S242U, Siera; Belgien

Country:  Belgium
Manufacturer / Brand:  Siera; Belgien
Year: 1949/1949 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCH42 UAF42 UBC41 UL41 UY41
Main principle Superheterodyne (common); ZF/IF 452 kHz
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 110-220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: S242U - Siera; Belgien
Material Bakelite case
Notes Available in cream (Hfl 160,-) and brown (Hfl 155,-).
External source of data E. Erb 3-907007-36-0
Circuit diagram reference Die «Thali Schemasammlung» führt das Modell.
Mentioned in Technisch- Commercieel - Radio Vademecum Staleman


All listed radios etc. from Siera; Belgien
Here you find 435 models, 394 with images and 178 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
