SA1022U

SA1022U; Siera; Eindhoven NL (ID = 807229) Radio SA1022U; Siera; Eindhoven NL (ID = 1030562) Radio
SA1022U; Siera; Eindhoven NL (ID = 1030563) Radio SA1022U; Siera; Eindhoven NL (ID = 1030564) Radio
SA1022U; Siera; Eindhoven NL (ID = 1030565) Radio SA1022U; Siera; Eindhoven NL (ID = 1030566) Radio
SA1022U; Siera; Eindhoven NL (ID = 1030567) Radio
Use red slider bar for more.
SA1022U; Siera; Eindhoven NL (ID = 807229) Radio
Siera; Eindhoven NL: SA1022U [Radio] ID = 807229 510x395
Select picture or schematic to display from thumbnails on the right and click for download.
For model SA1022U, Siera; Eindhoven (NL):
My own collection.

Country:  Netherlands
Manufacturer / Brand:  Siera; Eindhoven (NL)
Year: 1956 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: UCC85 UCH81 UF89 UABC80 UL41 UY85
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage AC/DC-set / 127; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: SA1022U - Siera; Eindhoven NL
Material Bakelite case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 290 x 200 x 165 mm / 11.4 x 7.9 x 6.5 inch
Net weight (2.2 lb = 1 kg) 3.4 kg / 7 lb 7.8 oz (7.489 lb)

Model page created by Hugo Sneyers. See "Data change" for further contributors.
