• Country
• Belgium

• Manufacturer / Brand
• Siera; Belgien

• Year
• 1956 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 332063

• Number of Tubes
• 6

• Valves / Tubes
• UCC85 UCH81 UF89 UABC80 UL84 UY85

• Main principle
• Superheterodyne (common); ZF/IF 452/10700 kHz

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• AC/DC-set / 127; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Bakelite case

• from Radiomuseum.org
• Model: SA1023U - Siera; Belgien

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 290 x 207 x 170 mm / 11.4 x 8.1 x 6.7 inch

• Notes

• Two dial lamps 8089D-00, 12 V / 0.1 A,

• Net weight (2.2 lb = 1 kg)
• 3.3 kg / 7 lb 4.3 oz (7.269 lb)

• Author
• Model page created by José Manuel Silvestre. See "Data change" for further contributors.
