- Country
- United States of America (USA)
- Manufacturer / Brand
- Simplex Radio Co.; Philadelphia, PA and Sandusky, OH
- Year
- 1936 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 254000
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Number of Transistors
- Semiconductors
- K38B2
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- AC/DC-set
- Loudspeaker
- Permanent or electro-dynamic (moving coil), system not known yet. / Ø 6.5 inch = 16.5 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: D [Console] - Simplex Radio Co.;
- Shape
- Console with any shape - in general
- Dimensions (WHD)
- 18.5 x 32 x 8.5 inch / 470 x 813 x 216 mm
- Notes
-
Tunes 15-55 and 170-555 meters, AVC, tone control.
- Net weight (2.2 lb = 1 kg)
- 17 lb 0 oz (17 lb) / 7.718 kg
- Price in first year of sale
- 37.45 $
- Literature/Schematics (3)
- -- Original prospect or advert (The Simplex Folder ca. for 1936.)
- Author
- Model page created by Ernst Erb. See "Data change" for further contributors.
